TCXOs

Product Selector

Select your specific requirements to find the products you need.

CLEAR ALL Products: 46
Frequency
Product Type
Package
Package Height mm (<=)
Stability ppm (<=)
Operating Temperature Range °C
Output Type
Supply Voltage V
Pullability ppm (>=)
loading...

Product Type : TCXO

The product image will be updated soon
2.0 x 1.6 x 0.8mm

GTXO-203T

1.8V ~ 3.6V SM (VC)TCXO

GTXO-203T features an ultra-miniature 2016 package with maximum height of 0.8mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.

  • 26.0 ~ 52.0MHz
  • Ideally suited for wearable applications
  • Supply voltages from 1.8V ~ 3.6V
  • Low power consumption
VIEW PRODUCT
The product image will be updated soon
2.0 x 1.6 x 0.8mm

GTXO-203V

1.8V ~ 3.6V SM (VC)TCXO
GTXO-203V features an ultra-miniature 2016 package with maximum height of 0.8mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
  • 26.0 ~ 52.0MHz
  • Ideally suited for wearable applications
  • Supply voltages from 1.8V ~3.6V
  • Low power consumption
VIEW PRODUCT
The product image will be updated soon
2.5 x 2.0 x 1.1mm

GTXO-253T

1.8V ~ 3.6V SM (VC)TCXO for GPS
GTXO-253T features an ultra-miniature 2520 package with maximum height of 1.1mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
  • 10.0 ~ 52.0MHz
  • Ideally suited for GPS applications
  • Fixed-frequency and voltage-controlled variants
  • Supply voltage from 1.8V ~ 3.6V
VIEW PRODUCT
The product image will be updated soon
2.5 x 2.0 x 1.1mm

GTXO-253V

1.8V ~ 3.6V SM (VC)TCXO for GPS
GTXO-253V features an ultra-miniature 2520 package with maximum height of 1.1mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
  • 10.0 ~ 52.0MHz
  • Ideally suited for GPS applications
  • Fixed-frequency and voltage-controlled variants
  • Supply voltage from 1.8V ~ 3.6V
VIEW PRODUCT
GTXO-94L

GTXO-94L
VIEW PRODUCT
The product image will be updated soon
2.5 x 2.0 x 0.95mm

GTXO-C25J

2.5V ~ 3.3V SM TCXO CMOS
GTXO-C25J features an ultra-miniature 2520 package with maximum height of 1.0mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
2.5 x 2.0 x 0.95mm

GTXO-C25K

2.5V ~ 3.3V SM TCXO CMOS
GTXO-C25K features an ultra-miniature 2520 package with maximum height of 1.0mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
2.5 x 2.0 x 0.95mm

GTXO-C25L

2.5V ~ 3.3V SM TCXO CMOS
GTXO-C25L features an ultra-miniature 2520 package with maximum height of 1.0mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
DIL-14

GTXO-14T

3.3 & 5V Stratum 3 Clipped Sine TCXO
The GTXO-14T TCXO from Golledge with SINE output comes encased in a robust DIL-14 package, and has excellent stability options, with stratum 3 compliant models available. You can find full specifications here, including all configurable options.
  • 6.4 ~ 100MHz
  • Ideally suited for Telecomms applications
  • 3.3V or 5.0V supply voltage
  • Clipped Sine output
VIEW PRODUCT
The product image will be updated soon
DIL-14

GTXO-14V

3.3 & 5V Stratum 3 Clipped Sine TCXO
The GTXO-14V TCXO from Golledge with SINE output comes encased in a robust DIL-14 package, and has excellent stability options, with stratum 3 compliant models available. You can find full specifications here, including all configurable options.
  • 6.4 ~ 100MHz
  • Ideally suited for Telecomms applications
  • 3.3V or 5.0V supply voltage
  • Clipped Sine output
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-560N

3V & 5V SM (VC)TCXO Clipped Sine
The GTXO-560N temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 10.0 ~ 40.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Low power consumption
  • Stabilities down to ±1.0ppm
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-560T

3V & 5V SM (VC)TCXO Clipped Sine
The GTXO-560T temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 10.0 ~ 40.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Low power consumption
  • Stabilities down to ±1.0ppm
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-560V

3V & 5V SM (VC)TCXO Clipped Sine
The GTXO-560V temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 10.0 ~ 40.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Low power consumption
  • Stabilities down to ±1.0ppm
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-566N

3V & 5V SM (VC)TCXO Clipped Sine
The GTXO-566N temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 10.0 ~ 40.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Low power consumption
  • Stabilities down to ±1.0ppm
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-566T

3V & 5V SM (VC)TCXO Clipped Sine
The GTXO-566T temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 10.0 ~ 40.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Low power consumption
  • Stabilities down to ±1.0ppm
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-566V

3V & 5V SM (VC)TCXO Clipped Sine
The GTXO-566V temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 10.0 ~ 40.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Low power consumption
  • Stabilities down to ±1.0ppm
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-570A

5V SM VCTCXO Wide Pulling Range
The GTXO-570A temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 22.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 22.0MHz
  • Wide voltage control range
  • 2.0mm maximum height
  • Good frequency stability
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-570B

5V SM VCTCXO Wide Pulling Range
The GTXO-570B temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 22.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 22.0MHz
  • Wide voltage control range
  • 2.0mm maximum height
  • Good frequency stability
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-570C

5V SM VCTCXO Wide Pulling Range
The GTXO-570C temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 22.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 22.0MHz
  • Wide voltage control range
  • 2.0mm maximum height
  • Good frequency stability
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-576A

5V SM VCTCXO Wide Pulling Range
The GTXO-576A temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 26.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 26.0MHz
  • Wide voltage control range
  • 2.0mm maximum height
  • Good frequency stability
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-576B

5V SM VCTCXO Wide Pulling Range
The GTXO-576B temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 26.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 26.0MHz
  • Wide voltage control range
  • 2.0mm maximum height
  • Good frequency stability
VIEW PRODUCT
The product image will be updated soon
11.8 x 9.9 x 2.0mm

GTXO-576C

5V SM VCTCXO Wide Pulling Range
The GTXO-576C temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 26.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 26.0MHz
  • Wide voltage control range
  • 2.0mm maximum height
  • Good frequency stability
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 2.5mm

GTXO-74T

3.0V VCTCXO Sine Low Phase Noise
The GTXO-74T temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 30.0 ~ 61.44MHz
  • Low phase noise
  • Clipped sine output, 0.7V p-p
  • Miniature SM package
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 2.5mm

GTXO-74V

3.0V VCTCXO Sine Low Phase Noise
The GTXO-74V temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 30.0 ~ 61.44MHz
  • Low phase noise
  • Clipped sine output, 0.7V p-p
  • Miniature SM package
VIEW PRODUCT
The product image will be updated soon
5.0 x 3.2 x 1.15mm

GTXO-83T

2.4V ~ 5.5V SM (VC)TCXO Clipped Sine
The GTXO-83T temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 6.0 ~ 45.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Supply voltage from 2.4V ~ 5.5V
  • Low power consumption
VIEW PRODUCT
The product image will be updated soon
5.0 x 3.2 x 1.15mm

GTXO-83V

2.4V ~ 5.5V SM (VC)TCXO Clipped Sine
The GTXO-83V temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 6.0 ~ 45.0MHz
  • Fixed-frequency and voltage-controlled variants
  • Supply voltage from 2.4V ~ 5.5V
  • Low power consumption
VIEW PRODUCT
GTXO-91T
3.2 x 2.5 x 1.0mm

GTXO-91T

1.8V ~ 3.3V SM (VC)TCXO Clipped Sine
The GTXO-91T temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 8.0 ~ 52.0MHz
  • Ideally suited for wireless applications
  • Supply voltage from 1.8V ~3.3V
  • Excellent frequency stability over -40 ~ +85°C
VIEW PRODUCT
GTXO-91V
3.2 x 2.5 x 1.0mm

GTXO-91V

1.8V ~ 3.3V SM (VC)TCXO Clipped Sine
The GTXO-91V temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 8.0 ~ 52.0MHz
  • Ideally suited for wireless applications
  • Supply voltage from 1.8V ~3.3V
  • Excellent frequency stability over -40 ~ +85°C
VIEW PRODUCT
GTXO-93T
3.2 x 2.5 x 1.2mm

GTXO-93T

1.8V ~ 3.6V SM (VC)TCXO for GPS
The GTXO-93T temperature compensated oscillator from Golledge is available at frequencies from 10.0 ~ 40.0MHz and features a range of configurable options, including wide pulling range options. Find full specifications here.
  • 10.0 ~ 40.0MHz
  • Analogue compensation - no steps
  • Ideally suited for GPS applications
  • Supply voltage from 1.8V ~ 3.6V
VIEW PRODUCT
GTXO-93V
3.2 x 2.5 x 1.2mm

GTXO-93V

1.8V ~ 3.6V SM VCTCXO for GPS
Ideal for GPS applications the GTXO-93V with voltage control also features analogue compensation, ensuring smooth output at variable temperatures. This miniature 3.2 x 2.5mm footprint component also features exceptional stability performance, with options as good as ±0.5ppm and power consumption as low as 1.5mA.
  • 10.0 ~ 40.0MHz
  • ±0.5ppm stability available
  • In-built voltage control
  • Low power consumption
VIEW PRODUCT
The product image will be updated soon
DIL-14

GTXO-C14T

3.3 & 5V Stratum 3 CMOS TCXO
The GTXO-C14T TCXO from Golledge with CMOS output comes encased in a robust DIL-14 package, and has excellent stability options, with stratum 3 compliant models available. You can find full specifications here, including all configurable options.
  • 1.0 ~ 100MHz
  • Ideally suited for Telecomms applications
  • 3.3V or 5.0V supply voltage
  • CMOS output
VIEW PRODUCT
The product image will be updated soon
DIL-14

GTXO-C14V

3.3 & 5V Stratum 3 CMOS TCXO
The GTXO-C14V TCXO from Golledge with CMOS output comes encased in a robust DIL-14 package, and has excellent stability options, with stratum 3 compliant models available. You can find full specifications here, including all configurable options.
  • 1.0 ~ 100MHz
  • Ideally suited for Telecomms applications
  • 3.3V or 5.0V supply voltage
  • CMOS output
VIEW PRODUCT
GTXO-C31J
3.2 x 2.5 x 1.1mm

GTXO-C31J

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C31J temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
GTXO-C31K
3.2 x 2.5 x 1.1mm

GTXO-C31K

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C31K temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
GTXO-C31L
3.2 x 2.5 x 1.1mm

GTXO-C31L

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C31L temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
5.0 x 3.2 x 1.15mm

GTXO-C51J

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C51J temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
5.0 x 3.2 x 1.15mm

GTXO-C51K

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C51K temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
5.0 x 3.2 x 1.15mm

GTXO-C51L

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C51L temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 2.5mm

GTXO-C74T

3.3V VCTCXO CMOS Low Phase Noise
The GTXO-C74T temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 30.0 ~ 61.44MHz
  • Low phase noise
  • CMOS output
  • Miniature SM package
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 2.5mm

GTXO-C74V

3.3V VCTCXO CMOS Low Phase Noise
The GTXO-C74V temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 30.0 ~ 61.44MHz
  • Low phase noise
  • CMOS output
  • Miniature SM package
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 1.5mm

GTXO-C75J

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C75J temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 1.5mm

GTXO-C75K

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C75K temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
7.0 x 5.0 x 1.5mm

GTXO-C75L

2.5V ~ 3.3V SM TCXO CMOS
The GTXO-C75L temperature compensated oscillator is available with excellent stability options over automotive operating temperature range of -40 to +85 degrees, making it ideal for a wide range of projects, including in-dash and V2V applications.
  • 675kHz ~ 55.0MHz
  • Supply voltages from 2.5V ~ 3.3V
  • Low power consumption
  • Enable / disable tristate function
VIEW PRODUCT
The product image will be updated soon
DIL-14

GTXO-S14T

3.3 & 5V Stratum 3 Sinewave TCXO
The GTXO-S14T TCXO from Golledge with SINE output comes encased in a robust DIL-14 package, and has excellent stability options, with stratum 3 compliant models available. You can find full specifications here, including all configurable options.
  • 6.4 ~ 52.0MHz
  • Ideally suited for Telecomms applications
  • 3.3V or 5.0V supply voltage
  • Sinewave output
VIEW PRODUCT
The product image will be updated soon
DIL-14

GTXO-S14V

3.3 & 5V Stratum 3 Sinewave TCXO
The GTXO-S14V TCXO from Golledge with SINE output comes encased in a robust DIL-14 package, and has excellent stability options, with stratum 3 compliant models available. You can find full specifications here, including all configurable options.
  • 6.4 ~ 52.0MHz
  • Ideally suited for Telecomms applications
  • 3.3V or 5.0V supply voltage
  • Sinewave output
VIEW PRODUCT
Custom TCXO

Custom TCXO
VIEW PRODUCT
