GTXO-253V 1.8V ~ 3.6V SM (VC)TCXO for GPS

  • Ideally suited for GPS applications
  • Fixed-frequency and voltage-controlled variants
  • Supply voltage from 1.8V ~ 3.6V
  • Low power consumption
  • Miniature SM package
DOWNLOAD PDF
Configurable Options
ParameterOption Code
Frequency
Frequency stability
J
H
G
F
E
Temperature range
C
N
S
I
Supply voltage (VDD)
Quantity / Special Request

Please specify the quantity you require below.

The GTXO-253V is supplied on tape and reel. 1k or 3k pcs per reel are the standard T&R pack sizes for this product. Partial quantities may be supplied on tape (no reel), or in bulk.
Product Description
GTXO-253V features an ultra-miniature 2520 package with maximum height of 1.1mm. This TCXO also offers a range of tight stability and other specification options including operating temperature range. You can find full specifications, and configurable options, here.
Specifications
Frequency range 10.0 ~ 52.0MHz
Dimensions 2.5 x 2.0 x 1.1mm
Storage temperature range -40 to +85°C
Supply voltage stability ±0.2ppm, VDD ±5%
Load stability ±0.2ppm, ZL ±10%
Frequency slope ±0.05ppm/°C over -30+85°C
Ageing ±1.0ppm max first year
Supply current 1.5~2.0mA max
Output waveform Clipped sine, 0.8V p-p, +DC offset
Test load (ZL) 10kΩ // 10pF
Start up time 3ms max
Frequency adjustment ±8 ~ ±14ppm, +1.4V ±1.0V
Harmonics -5dBc max
Phase noise -130dBc/Hz @ 1kHz
Frequency tolerance @ 25°C ±2.0ppm max, 60mins after reflow
Package Drawing
Package footprint and pad configuration drawing for the Golledge GTXO-253V TCXO showing full dimensions.
Ordering Information

To request a quotation for the GTXO-253V please use the configurable options form to choose the options you require and then submit your configured product to our team. Our expert advisers are always happy to help with your requirements and can be contacted on +44 1460 256 100 or at sales@golledge.com.

Following product selection you will be issued with a seven character Golledge part number. Your Golledge part number is the internationally accepted Golledge manufacturing part number (MPN) that should be used for all project documentation, including bills of materials (BoMs) and purchase orders.

If you have any queries regarding any of our documentation our dedicated sales team will be happy to help.

CAD Models
Our GTXO-253V is included in the following design libraries. Click to download the library of your choice.

Autodesk Eagle

Altium

Pulsonix
Marking
Marking
Soldering Profile
Solder reflow profile
Tape & Reel Specification
Tape and Reel specifications
Handling & Storage

ESD-HBM-1A Human Body Model (HBM) 1A (250V to < 500V)

MSL1 Moisture Sensitivity Level (MSL): 1

Construction
Ceramic body with gold-plated pads Metal lid, seam sealed
Compliance

PbFree Lead-free (< 0.1% by weight )

RoHS RoHS compliant with no exemptions.
