GTXO-203T
1.8V ~ 3.6V SM (VC)TCXO
- Ideally suited for wearable applications
- Supply voltages from 1.8V ~3.6V
- Low power consumption
- Miniature SM package
- Excellent frequency stability
Specifications
| Frequency range |
26.0 ~ 52.0MHz |
| Dimensions |
2.6 x 1.0 x 0.8mm |
| Storage temperature range |
-40 to +85°C |
| Supply voltage stability |
±0.2ppm, VDD ±5% |
| Load stability |
±0.2ppm, ZL ±10% |
| Ageing |
±1.0ppm max first year |
| Supply current |
1.5~2.0mA max |
| Output waveform |
Clipped sine, 0.8V p-p, +DC offset |
| Test load (ZL) |
10kΩ // 10pF |
| Start up time |
3ms max |
| Harmonics |
-5dBc max |
| Phase noise |
-130dBc/Hz @ 1kHz |
| Frequency tolerance @ 25°C |
±2.0ppm max, 60mins after reflow |
Package Drawing
Ordering Information
To request a quotation for the GTXO-203T please use the configurable options form to choose the options you require and then submit your configured product to our team. Our expert advisers are always happy to help with your requirements and can be contacted on +44 1460 256 100 or at sales@golledge.com.
Following product selection you will be issued with a seven character Golledge part number. Your Golledge part number is the internationally accepted Golledge manufacturing part number (MPN) that should be used for all project documentation, including bills of materials (BoMs) and purchase orders.
If you have any queries regarding any of our documentation our dedicated sales team will be happy to help.
Marking
Soldering Profile
Tape & Reel Specification
Handling & Storage
Human Body Model (HBM) 1A (250V to < 500V)
Moisture Sensitivity Level (MSL): 1
Construction
Ceramic body with gold-plated pads Metal lid, seam sealed
Compliance
Lead-free (< 0.1% by weight )
RoHS compliant with no exemptions.
