GFO-3301

GFO-3301 1.5~5.5V 32.768kHz Oscillator

  • Extremely low current consumption
  • Operational from 1.5V ~ 5.5V
  • Tuning fork resonator
  • Miniature ceramic package with metal lid
  • Competitive pricing
DOWNLOAD PDF
Configurable Options
ParameterOption Code

The GFO-3301 has no configurable options.
Please see the specifications table for more details or contact our team today if you have other specification requirements.

Quantity / Special Request

Please specify the quantity you require below.

The GFO-3301 is supplied on tape and reel. 1k or 3k pcs per reel are the standard T&R pack sizes for this product. Partial quantities may be supplied on tape (no reel), or in bulk.
Product Description
The miniature 3225 package GFO-3301 oscillator is available at frequencies from 32.768kHz and features a range of temperature stability and other specification options. Find full specifications here.
Package Drawing
Golledge 3225 SM oscillator package
Ordering Information

To request a quotation for the GFO-3301 please use the configurable options form to choose the options you require and then submit your configured product to our team. Our expert advisers are always happy to help with your requirements and can be contacted on +44 1460 256 100 or at sales@golledge.com.

Following product selection you will be issued with a seven character Golledge part number. Your Golledge part number is the internationally accepted Golledge manufacturing part number (MPN) that should be used for all project documentation, including bills of materials (BoMs) and purchase orders.

If you have any queries regarding any of our documentation our dedicated sales team will be happy to help.

CAD Models
Our GFO-3301 is included in the following design libraries. Click to download the library of your choice.

Autodesk Eagle

Altium

Pulsonix
Enable / Disable Function
Input (pad 1) Output (pad 3)
Open Enabled
'1' level (VIH=70% VDD min) Enabled
'0' level (VIL=30% VDD min) High Impedance
Marking
Marking
Marking
Soldering Profile
Solder reflow profile
Tape & Reel Specification
Tape and Reel specifications
Handling & Storage

ESD-HBM-1A Human Body Model (HBM) 1A (250V to < 500V)

MSL1 Moisture Sensitivity Level (MSL): 1

Construction
Ceramic body with gold-plated pads, Metal lid, seam sealed
Compliance

PbFree Lead-free (< 0.1% by weight )

RoHS RoHS compliant with no exemptions.
